Hex milling insert - face milling 45°/60° (45°/30°)

indexable insert for milling

• Application Area: MU
• Coating Process Type: CVD
• Corner chamfer width (CHW): 0.8 mm
• Corner chamfer angle (KCH): 37 deg
• Inscribed circle (IC): 15,875 mm
• Setting angle, main cutting edge (KRINS): 75 deg
• fz max: 0.20999999999999999 mm
• fz min: 0.10000000000000001 mm
• fz rec: 0.17999999999999999 mm
• Manufacturer item number: SPKN 15 04 ED L 4230
• Manufacturer: SANDVIK COROMANT
• IC Code: 18000
• ISO Cutting Tool Material: HC
• Life Cycle Status (LCS): 20
• Cutting edge width (BS): 1.4 mm
• Cutting length, limited (LE): 13.5 mm
• Cutting length, max. (APMX): 12 mm
• Cutting edge height (S): 4.7625 mm
• Cutting insert shape (SC): S
• Cutting insert size and shape (CUTINT_SIZESHAPE): SP1504ED
• Cutting direction (HAND): L
• Grade: 4230
• Substrate Type: WC
• TMC Order: 1~2
• vc max: 185~280 m/min
• vc min: 155~230 m/min
• vc rec: 160~245 m/min
• Material classification level 1(TMC1): K~P
• Grade: 4230
• All ISO application areas: P|K
