Hex milling insert - face milling 45°/60° (45°/30°)

indexable insert for milling

• Coating Process Type: CVD
• Corner chamfer width (CHW): 0.8 mm
• Corner chamfer angle (KCH): 37 deg
• Corner radius (RE): 0.85 mm
• Inscribed Circle (IC): 12.7 mm
• Setting angle, main cutting edge (KRINS): 75 deg
• Manufacturer item number: SPKN 12 03 ED L 4230
• Manufacturer: SANDVIK COROMANT
• IC Code: 18000
• ISO Cutting Tool Material: HC
• Life Cycle Status (LCS): 20
• Cutting edge width (BS): 1.6 mm
• Cutting length, limited (LE): 10.3 mm
• Cutting length, max. (APMX): 9 mm
• Cutting edge height (S): 3.175 mm
• Cutting insert shape (SC): S
• Cutting insert size and shape (CUTINT_SIZESHAPE): SP1203ED
• Cutting direction (HAND): L
• Grade: 4230
• Substrate Type: WC
• Corner radius R: 0.85 mm
• Grade: 4230
• All ISO application areas: P|K
