Hex milling insert - face milling 45°/60° (45°/30°)

indexable insert for milling

• Application Area: MU
• Coating Process Type: CVD
• Corner chamfer width (CHW): 0.8 mm
• Corner chamfer angle (KCH): 37 deg
• Corner radius (RE): 0.85 mm
• Inscribed Circle (IC): 12.7 mm
• Setting angle, main cutting edge (KRINS): 75 deg
• fz max: 0.20999999999999999 mm
• fz min: 0.10000000000000001 mm
• fz rec: 0.17999999999999999 mm
• Manufacturer item number: SPKN 12 03 ED R 3040
• Manufacturer: SANDVIK COROMANT
• IC Code: 18000
• ISO Cutting Tool Material: HC
• Life Cycle Status (LCS): 20
• Cutting edge width (BS): 1.6 mm
• Cutting length, limited (LE): 10.3 mm
• Cutting length, max. (APMX): 9 mm
• Cutting edge height (S): 3.175 mm
• Cutting insert shape (SC): S
• Cutting insert size and shape (CUTINT_SIZESHAPE): SP1203ED
• Cutting direction (HAND): R
• Grade: 3040
• Substrate Type: WC
• TMC Order: 1~2~3
• vc max: 210~275~40 m/min
• vc min: 175~225~32 m/min
• vc rec: 185~240~35 m/min
• Material classification level 1 (TMC1): H~K~P
• Corner radius R: 0.85 mm
• Grade: 3040
• All ISO application areas: P|K|H
