Hex milling insert - face milling 45°/60° (45°/30°)
Hex milling insert - face milling 45°/60° (45°/30°)
$40 (USD)
Location:Germany
Available quantity:99
orCall +1 (305) 951 -7825
Description
indexable insert for milling
- Application Area: MU
- Corner chamfer width (CHW): 0.8 mm
- Corner chamfer angle (KCH): 37 deg
- Corner radius (RE): 0.85 mm
- Inscribed Circle (IC): 12.7 mm
- Setting angle, main cutting edge (KRINS): 75 deg
- fz max: 0.19 mm
- fz min: 8.0000000000000002E-2 mm
- fz rec: 0.12 mm
- Manufacturer item number: SPKN 12 03 ED R 530
- Manufacturer: SANDVIK COROMANT
- IC Code: 18600
- ISO Cutting Tool Material: HT
- Life Cycle Status (LCS): 20
- Cutting edge width (BS): 1.6 mm
- Cutting length, limited (LE): 10.3 mm
- Cutting length, max. (APMX): 9 mm
- Cutting edge height (S): 3.175 mm
- Cutting insert shape (SC): S
- Cutting insert size and shape (CUTINT_SIZESHAPE): SP1203ED
- Cutting direction (HAND): R
- Grade: 530
- Substrate Type: CERMET
- TMC Order: 1~2~3~4
- vc max: 280~315~75~960 m/min
- vc min: 225~260~60~830 m/min
- vc rec: 255~290~70~910 m/min
- Material classification level 1 (TMC1): H~M~N~P
- Corner radius R: 0.85 mm
- Grade: 530
- All ISO application areas: P|M|K
Specifications
Manufacturer | SANDVIK COROMANT |
Model | SPKN1203EDR530 |
Year | 2024 |
Condition | New |
Serial Number | 520 SPKN 12 03 ED R 530 |
Stock Number | . |
