Hex milling insert - face milling 45°/60° (45°/30°)

indexable insert for milling

• Application Area: MU
• Coating Process Type: CVD
• Corner chamfer angle (KCH): 44 deg
• Inscribed Circle (IC): 12.7 mm
• Setting angle, main cutting edge (KRINS): 90 deg
• fz max: 0.29999999999999999 mm
• fz min: 0.10000000000000001 mm
• fz rec: 0.25 mm
• Manufacturer's ArtNo: TPKR 22 04 PD R-WH 3040
• Manufacturer: SANDVIK COROMANT
• IC Code: 18000
• ISO Cutting Tool Material: HC
• Life Cycle Status (LCS): 20
• Cutting edge width (BS): 1.2 mm
• Cutting length, limited (LE): 18 mm
• Cutting length, max. (APMX): 18 mm
• Cutting edge height (S): 4.7625 mm
• Cutting insert shape (SC): T
• Cutting insert size and shape (CUTINT_SIZESHAPE): TP2204PD
• Cutting direction (HAND): R
• Grade: 3040
• Chip breaker, manufacturer designation (CBMD): WH
• Substrate Type: WC
• TMC Order: 1~2~3
• vc max: 210~275~40 m/min
• vc min: 140~185~25 m/min
• vc rec: 155~205~28 m/min
• Material classification level 1 (TMC1): H~K~P
• Grade: 3040
• Cutting edge height: 4.7625 mm
• All ISO application areas: K
