Hex milling insert - face milling 45°/60° (45°/30°)

indexable insert for milling

• Application Area: MU
• Corner chamfer width (CHW): 0.4 mm
• Corner chamfer angle (KCH): 45 deg
• Inscribed Circle (IC): 12.7 mm
• Setting angle, main cutting edge (KRINS): 90 deg
• fz max: 0.20000000000000001 mm
• fz min: 0.10000000000000001 mm
• fz rec: 0.17000000000000001 mm
• Manufacturer's ArtNo: TPKN 22 04 PD R HM
• Manufacturer: SANDVIK COROMANT
• IC Code: 18000
• ISO Cutting Tool Material: HW
• Life Cycle Status (LCS): 20
• Cutting edge width (BS): 1.4 mm
• Cutting length, limited (LE): 18 mm
• Cutting length, max. (APMX): 18 mm
• Cutting edge height (S): 4.7625 mm
• Cutting insert shape (SC): T
• Cutting insert size and shape (CUTINT_SIZESHAPE): TP2204PD
• Cutting direction (HAND): R
• Grade: HM
• Substrate Type: WC
• TMC Order: 1
• vc max: 130 m/min
• vc min: 110 m/min
• vc rec: 115 m/min
• Material classification level 1 (TMC1): K
• Grade: HM
• Cutting edge height: 4.7625 mm
