Hex milling insert - face milling 45°/60° (45°/30°)

indexable insert for milling

• Application Area: MU
• Coating Process Type: CVD
• Corner chamfer angle (KCH): 44 deg
• Inscribed circle (IC): 9,525 mm
• Setting angle, main cutting edge (KRINS): 90 deg
• fz max: 0.29999999999999999 mm
• fz min: 0.10000000000000001 mm
• fz rec: 0.25 mm
• Manufacturer's ArtNo: TPKR 16 03 PP R-WH 4240
• Manufacturer: SANDVIK COROMANT
• IC Code: 18000
• ISO Cutting Tool Material: HC
• Life Cycle Status (LCS): 20
• Cutting edge width (BS): 1.2 mm
• Cutting length, limited (LE): 13 mm
• Cutting length, max. (APMX): 13 mm
• Cutting edge height (S): 3.175 mm
• Cutting insert shape (SC): T
• Cutting insert size and shape (CUTINT_SIZESHAPE): TP1603PP
• Cutting direction (HAND): R
• Grade: 4240
• Chip breaker, manufacturer designation (CBMD): WH
• Substrate Type: WC
• TMC Order: 1~2~3
• vc max: 170~185~240 m/min
• vc min: 115~120~160 m/min
• vc rec: 125~135~180 m/min
• Material classification level 1(TMC1): K~M~P
• Grade: 4240
• Cutting edge height: 3,175 mm
• All ISO application areas: P|K
