CoroMill S-60 turning insert, negative - KW geometry

CoroMill® S-60 indexable insert for milling

• Coating Process Type: CVD
• Corner chamfer width (CHW): 1.79 mm
• Corner chamfer angle (KCH): 50 deg
• Corner radius (RE): 0.8 mm
• Inscribed Circle (IC): 16.26 mm
• Setting angle, main cutting edge (KRINS): 60 deg
• Manufacturer's ArtNo: HNEF 09 05 08R-KW 3330
• Manufacturer: SANDVIK COROMANT
• IC Code: 18000
• ISO Cutting Tool Material: HC
• Life Cycle Status (LCS): 20
• Cutting edge width (BS): 4.9 mm
• Cutting length, limited (LE): 9.38 mm
• Cutting length, max. (APMX): 6 mm
• Cutting edge height (S): 5.56 mm
• Cutting insert shape (SC): H
• Cutting insert size and shape (CUTINT_SIZESHAPE): Mill S-60 HN0905xxxW
• Cutting direction (HAND): R
• Grade: 3330
• Chip breaker, manufacturer designation (CBMD): KW
• Substrate Type: WC
• Corner radius R: 0.8 mm
• Chipbreaker Manufacturer designation CBM: KW
• Cutting edge height: 5.56 mm
• Recommended variety: K
• All ISO application areas: K
