End mill square shape, without corner radius, with center cutting edge - Metric version

End mill square shape, without corner radius, with center cutting edge - Metric version

$150 (USD)

Location:Germany

Available quantity:99

orCall +1 (305) 951 -7825

Description

CoroMill® Plura solid carbide end mills for stability and


  • Adapter interface machine direction (ADINTMS): Weldon (DIN6535-HB) -metric: 8
  • Number of effective cutting edges, circumferential (ZEFP): 4
  • Basic Classification (BSG): DIN 6527 L
  • Coating Process Type: PVD
  • DCONMS: 8 mm
  • Helix angle (FHA): 50 deg
  • Speed, max. (-81, -82: Maximum speed)(RPMX): 80000 1/min
  • Corner chamfer width (CHW): 0.1 mm
  • Corner chamfer angle (KCH): 45 deg
  • Immersion angle, max.(RMPX): 5 deg
  • Functional diameter (DCF): 7.8 mm
  • Functional length (LF): 63 mm
  • Manufacturer item number: R216.34-08050-BC19P 1620
  • Manufacturer: SANDVIK COROMANT
  • IC Code: 10050
  • ISO Cutting Tool Material: HC
  • Coolant inlet (CNSC): 0: without coolant
  • Life Cycle Status (LCS): 20
  • Maximum regrinding operations (NORGMX): 2
  • Usable length (LU): 19 mm
  • Back rake angle (GAMP): 13.5 deg
  • Cutting diameter (DC): 8 mm
  • Cutting length, max. (APMX): 19 mm
  • Side rake angle (GAMF): 10.5 deg
  • Grade: 1620
  • Substrate Type: WC
  • Tolerance shaft diameter (TCDCON): h6
  • Center cutting ability (CCC): 1
  • Cutting diameter: 8 mm
  • Cutting length: 19 mm
  • Functional length L: 63 mm
  • Number of effective cutting edges on the circumference: 4
  • All ISO application areas: P|M|K|S


Specifications

ManufacturerSANDVIK COROMANT
ModelR216.34-08050-BC19P1620
Year2024
ConditionNew
Serial Number520 R216.34-08050-BC19P 1620
