CoroMill QD indexable inserts

CoroMill QD indexable inserts

$45 (USD)

Location:Germany

Available quantity:99

orCall +1 (305) 951 -7825

Description

CoroMill® QD indexable insert for grooving

  • Application Area: TP
  • Coating Process Type: CVD
  • Corner radius, left (REL): 0.4 mm
  • Corner radius, right (RER): 0.4 mm
  • fz max: 0.23999999999999999 mm
  • fz min: 5.0000000000000003E-2 mm
  • fz rec: 0.13 mm
  • Main clearance angle (AN): 7 deg
  • Manufacturer item number: QD-NH-0400-040M-KM 3330
  • Manufacturer: SANDVIK COROMANT
  • IC Code: 18000
  • ISO Cutting Tool Material: HC
  • Life Cycle Status (LCS): 20
  • Upper cutting width tolerance (CWTOLU): 0.105 mm
  • Cutting insert size and shape (CUTINT_SIZESHAPE): CoroMill QD -size H
  • Cutting direction (HAND): N
  • Grade: 3330
  • Chip breaker, manufacturer designation (CBMD): KM
  • Grooving width, nominal dimension (CW): 4 mm
  • Substrate Type: WC
  • TMC Order: 1
  • Lower cutting width tolerance (CWTOLL): 0.005 mm
  • vc max: 270 m/min
  • vc min: 240 m/min
  • vc rec: 255 m/min
  • Material classification level 1 (TMC1): K
  • Grooving width nominal dimension C: 4 mm
  • Corner radius right RE: 0.4 °
  • Grade: 3330
  • All ISO application areas: K



Specifications

ManufacturerSANDVIK COROMANT
ModelQD-NH-0400-040M-KM3330
Year2024
ConditionNew
Serial Number520 QD-NH-0400-040M-KM 3330
Stock Number.
