BALL TRANSMISSION WITH FASTENING ELEMENT, FORM:B STEEL, COMP:STEEL

Material: Galvanized steel. Order example: K0765.122 Note: Ball transfer units with fastening element can be easily assembled and disassembled from the functional side. They are fixed using spring-loaded claws. These allow large tolerances in the installation hole. They have a felt seal that protects against dirt. S = minimum nominal thickness of the receiving part. Drawing note: 1) Load ball 2) Support ball Form B: Cover and housing galvanized, balls made of steel Form C: Cover and housing galvanized, balls made of stainless steel

Technical features:

• Mounting diameter DB: 25 +0.5
• Version 1: with fastening element
• Mounting type: spring clip
• Name: Ball transfer unit
• D=Diameter: 24±0.1
• D1=Outer diameter: 31
• DK: 15.8
• Shape: B
• Weight in kg (ERP): 0.0397
• H=Height: 21
• H1=Height: 9.5
• H2: 2.8
• Material base body: steel
• Material Component: Steel
• Surface base body: galvanized
• RoHS: true
• S: 2
• Load capacity C (N): 600
• Country of origin: GB
• Customs tariff number: 83022000
